US troops and a Sherman with Culin hedgerow cutter advance on a Belgian town.
The M4 was originally designed to replace the (stopgap) M3 medium tank, as a
medium tank armed with a 75mm gun in a turret, and using many of the components
of the M3 to speed production. Two versions of the tank went into production at
the end of 1941. The M4 was a tank with a welded hull, characterized by the
sharp cornered hull shape, while the M4A1 featured a cast hull with a more
rounded shape. The reason for the two styles was that, in order to meet
production targets, factories without the ability to handle hull castings were
used. These firms could not produce the large armor castings needed for the
M4A1 hull, but they were able to produce the welded M4 hull. (In the end, the
welded hull variants out-numbered the cast hull versions.)
Sgt. Bill Hey and crew take time out of the cramped interior of their tank.
When the tank first entered combat in
North Africa in 1942, it was quite successful, but combat experience showed a
number of changes were needed. Some of the changes involved improving
protection, as the tank’s armor was insufficient to stand up to the larger
German guns. Additional armor was added at the depot level, by welding
additional armor over vulnerable areas, such as the ammo storage bins. This
armor was called “applique armor”. Additional soft armor was added by crews in
the field. This took the form of sandbags, logs, tracks, and other similar
materials. This type of add-on protection didn’t really help against anti-tank
cannon fire, but was effective against Panzerfaust (Germany’s version of the
bazooka) rocket propelled HE rounds.
Gunner Corporal 'Chuck' Miller keeps watch with his Thompson SMG.
The Sherman was first equipped with the with the L/40 75mm M3 Gun, which firing the usual M61 round could penetrate 77 mm at 100m and 61 mm at 1000m. Conditions later in the war necessitated the up-gunning to the L/55 76mm M1A2, which could penetrate 124 mm at 100m and 83 mm at 1000m using the usual M79 round. The M1A2 helped to equalize the Sherman and the PzIV in terms of firepower, although the M4 was still under-powered compared to the Panther's much more powerful L/70 75mm gun.
Corporal Miller in action.
The British-developed Sherman Firefly was up-gunned with the 17 pdr. gun. The 17 pdr. also was 76 mm and had a L/55 barrel, but it introduced a much bigger charge which allowed it to penetrate 140 mm at 100m and 120 mm at 1000m using Mk.IV shot. This gun allowed the Firefly a slight firepower advantage over the Panther, although the blinding muzzle flash due to unburnt powder from the increased charge was a handicap.
Sherman at the Imparial War Museum.
The U.S. Army restricted the Sherman's height, width, and weight so that it could be transported via typical bridges, roads, and railroads. This aided strategic, logistical, and tactical flexibility.
Sherman at the Imperial War Museum.
The Sherman had good speed both on- and off-road. Off-road performance varied. In the desert, the Sherman's rubber tracks performed well. In the confined, hilly terrain of Italy, the Sherman could often cross terrain that some German tanks could not.
Tank crew at Fort Knox 1942.
M4 Sherman on Wikipedia.
Sherman M4 tank from a plastic 1/48 scale Tamiya kit. Crew are by Artizan.
